Current Version Sundance® Spas Pump 6500-343 Energy Saver 2 Speed 2.5 HP 230 Volt 3450/1725 RPM

6500-343 Current Version Sundance® Spas Pump Energy Saver 2 Speed 2.5 HP 230 Volt 3450/1725 RPM

Specifications: Latest Version-Energy Saver Pump
Click here to purchase the required Pump Bracket & 2" Orings

• 11 / 3.3 Amp
• 2 Speed
• 3450 / 1725 RPM
• 2.5 HP / 4.2 Brake HP
• 230 Volt
• 48 Frame
• Union connection: The inlet and outlet inner diameter is 2".  The outer diameter is 3 1/16".
• The wet end can be rotated to desired position.
• Red Wire for High Speed, Black Wire for Low Speed, White Wire for Common, Green Wire for Ground

FREE Step by Step Video How to install this pump.  Emailed upon request after purchase

If you need help matching up your old pump, send photos to help@spastore.com
Be sure to include photos all stickers on the pump and hot tub model & year if known.

Note: This is a newer style pump and requires the use of a separately sold Pump Bracket below:

Click here to purchase the required Pump Bracket & 2" Orings

This is a newer pump design. Your old pump had the mounting base attached to the bottom of the pump.
The new design requires a separate pump bracket for easier installation.
The new pump does not come with an electrical cord. Reuse the electrical cord from the pump being replaced.
