CURRENT VERSION 1.5 HP replaced 2.0 HP Jacuzzi® Jetted Bath Tub Whirlpool Pump 115V RPM 3450 Replaced Obsolete 2.0 HP Emerson C55CXJJL-4505 With 1-1/2" Connection Fitting

CURRENT VERSION 1.5 HP replaced 2.0 HP Jacuzzi® Jetted Bath Tub Whirlpool Pump 115V RPM 3450
Replaced Emerson C55CXJJL-4505

***Note:  New fitting is 1.5" instead of Old fitting 2".  Simple solution is to use a pvc reducer from 2" to 1.5".

1.5" Pump thread measures approx. 2-3/8" O.D.
2.0" Pump thread measures approx. 3" O.D.

Speed 1 Speed (1-Spd)
Motor Voltage 115v
Suction Style Bottom
Suction Connection Type Male Buttress Thread (mbt)
Suction Pipe Size 1-1/2"
Discharge Style Center
Discharge Connection Type Male Buttress Thread (mbt)
Discharge Pipe Size 1-1/2"
Horsepower 1.5 hp
Motor Frame 48 Frame Thru-Bolt
Motor Amperage/Wattage 13.0A
Dimensions: 13-7/8"L x 6-1/8"W x 8-5/16"H
